Easy to assemble and disassemble for several times without damage.
Could be lifted, fixed and combined freely to meet various needs.
Heatproof and waterproof design with a service life of 10-15 years (up to 20+ for main structure).
Convenient transportation; 4 container houses can be loaded in one 20ft standard container.
| Standard Specification Performance | |
|---|---|
| Wind Resistance | Grade 11 (wind speed ≤ 111.5km/h) |
| Earthquake Resistance | Grade 7 |
| Fire Proof Rating | B2 Grade |
| Live Load of Roofing | 0.5kn/m² |
| Live Load of Floor | 2.0kn/m² |
| Heat Transmission Coefficient | 0.35Kcal/m²hc |
Material: Light steel structure Q235. Surface treatment includes sand blasting, epoxy basic painting (55μm), and final vinyl acrylic painting (55μm). Includes standard container corner fittings and PVC rainwater pipes.
Floor: 4mm steel girder with 75mm rock wool insulation. 15mm plywood for general rooms; 20mm cement board for wet areas. Finished with PVC leather or anti-slip aluminum board.
Ceiling: 1.2mm stamping steel plate exterior with 75mm rock wool insulation. Inner wainscot uses 9mm MDF laminated panel or 10mm glass magnesium fire-proof board.
Walls: 75mm total thickness. 0.5mm galvanized and painted steel sheets. Insulation options: EPS (12kg/m³), Rock Wool (120kg/m³), or PU (45kg/m³).
External Door: Sandwich panel door (850*2100mm) with cylinder lock. Aluminum frame with 50mm EPS insulation.
Windows: White PVC sliding windows (1130*1000mm) with fly screens or rolling shutters.
| NO. | ITEMS | DESCRIPTION |
|---|---|---|
| 1 | MATERIAL | Light steel structure material Q235 |
| 2 | WALL | Sandwich panel with steel plate surface (75mm) |
| 3 | ROOF | 1.2mm steel plate + 75mm Rock Wool + 9mm MDF |
| 4 | WINDOWS | PVC sliding window |
| 5 | DOORS | Aluminum frame with 50mm EPS insulation |
✅ Efficient Packing: Bulk packing in container loading. One 40HQ container can load 5 units of 20ft container houses.
